FLRY-nx 汽车用电缆由绞合或平行配置的 FLRY-A/B 电线组成，符合 ISO 6722 标准，耐温等级达 105°C。具备良好的抗噪讯能力、柔软性与紧凑布线特性，适用于控制系统与感测器线束应用。


FLRY-nx Automotive Wire – Twisted Pair or Multi-Core Thin-Wall 105°C PVC Wire for Vehicle Data & Signal Transmission

FLRY-nx wire is a twisted pair or multi-core automotive cable constructed with two or more FLRY-A or FLRY-B wires bundled in a parallel or twisted configuration. Designed for optimized electromagnetic noise immunity, space-saving installation, and flexible harnessing, FLRY-nx is ideal for automotive control, signal, and sensor transmission.

Built to ISO 6722 standards, FLRY-nx cables are insulated with thin-wall PVC and rated for 105°C. Their structure supports high bendability, compact routing, and stable transmission in critical control and safety-related vehicle systems.


Key Features

  • Core Structure: 2 or more FLRY-A or FLRY-B wires

  • Conductor: Fine- or standard-stranded bare/tinned copper

  • Insulation: Thin-wall lead-free PVC

  • Temperature Rating: -40°C to 105°C

  • Voltage Rating: 60V (standard LV automotive systems)

  • Configuration: Twisted pair (for EMI reduction) or parallel multi-core

  • Noise Immunity: Enhanced via twisting for critical signal circuits

  • Color Coding: Multiple color/stripe combinations for easy identification

  • RoHS Compliant: Free of hazardous substances


Common Applications

  • CAN bus systems, LIN bus, and other vehicle communication networks

  • Sensor and data wiring in safety modules (e.g., ABS, airbags)

  • Wiring for camera systems, driver-assist modules, or infotainment

  • Signal lines requiring EMI suppression or matched impedance

  • Compact vehicle harness designs with multi-core integration
